The 120mm suspension fork soaks up rocks, roots and bumps, while the 9-speed Shimano CUES drivetrain is durable and reliable, ideal for tackling any terrain.< /p>
The adaptive motor with AUTO mode recognizes speed reductions and adjusts assistance automatically.
The 120 mm suspension maintains smoothness when rolling over rocks, roots and complicated terrain.
The Marlin+ is easy to use with simple controls and intuitive assistance so you can focus on the ride ahead.
Its trail-ready geometry offers easy, confident handling on both singletrack and city streets.
It is equipped with several mounts for racks and fenders that allow you to customize your bike for riding on trails or for your daily trips around the city.
It is ideal for you if...
You're looking for a bike with an extra dose of power for the trails without costing you an arm and a leg. You love the Marlin's ability to go from the trails to the city, and you want a bike that helps you go a little faster or pedal further.
Frame Assembly
*Picture
Size: XS
Alpha Platinum Aluminum, bent top tube, tapered head tube, internal routing, rack mount, fenders and kickstand, UDH, Boost148, 12mm thru axle
Size: S, M, L, XL
Alpha Platinum Aluminum, tapered head tube, internal routing, rack mount, fenders and kickstand, UDH, Boost148, 12mm thru axle
*Fork
Size: XS
SR Suntour XCM 34, spring, preload, lockout, tapered steerer, 44mm offset, Boost110, 15mm thru axle, 100mm travel
Size: S, M, L, XL
SR Suntour
Wheels
Bontrager alloy front hub, sealed bearing, alloy axle, centerlock, Boost110, 15 mm thru axle
Formula CL-3248M rear hub, aluminum, CenterLock, Shimano 8/9/10 hub, Boost148, 12 mm thru axle
Rear closure Bontrager Switch thru axle, removable cam
Bontrager Connection rim, double wall, 32 holes, 20 mm width, Presta valve
*Cover
Size: XS, S
Bontrager XT3 Comp, wire rim, 30 tpi, 27.5 x 2.40"
Size: M, L, XL
Bontrager XT3 Comp, wire rim, 30 tpi, 29 x 2.40"
Transmission
Shimano U4000 shift lever, 9 speeds
Shimano CUES U4000 rear derailleur
FSA CK-220 bottom bracket, length 165 mm
FSA chainring, 32T, steel
Shimano LINKGLIDE LG300 cassette, 11-46, 9 speeds
Shimano LG500 chain, 9/10/11 speeds
Pedal Nylon platform VP-536
Components
Bontrager Arvada saddle, steel rails, width 138 mm
*Seatpost
Size: XS, S
Bontrager alloy, 31.6mm, 12mm offset, 330mm length
Size: M
Bontrager alloy, 31.6mm, 12mm offset, 360mm length
Size: L, XL
Bontrager alloy, 31.6mm, 12mm offset, 400mm length
*Handlebar
Size: XS, S
Bontrager aluminum, 31.8 mm, height 15 mm, width 720 mm
Size: M, L, XL
Bontrager aluminum, 31.8 mm, height 15 mm, width 750 mm
Bontrager XR Endurance Comp grips, lockout
*Power
Size: XS, S
Bontrager aluminum, 31.8 mm, Blendr compatible, 7 degrees, length 35 mm
Size: M, L
Bontrager aluminum, 31.8 mm, Blendr compatible, 7 degrees, 50 mm length
Size: XL
Bontrager aluminum, 31.8 mm, Blendr compatible, 7 degrees, 60 mm length
Semi-integrated headset, loose ball bearing, 1-1/8” at the top and 1.5” at the bottom
Tektro brake disc, centerlock, 203 mm
Brake set Tektro HD-M275 hydraulic disc
Accessories
Bosch CompactTube 400 Wh battery
Bosch standard 2A charger, 230 V, intelligent system
Bosch Active Line Plus motor, 50 Nm
Bosch Purion 200 cycle computer
Weight
Weight M - 22.45 kg / 49.5 lbs (with cameras)
Weight limit This bicycle has a maximum weight limit (combined weight of bicycle, rider and cargo) of 136 kg.
