It is ideal for you if...
You want a full-suspension trail bike that floats through the most demanding, technical terrain, and has additional benefits, like the root-absorbing FOX Rhythm fork and tubeless wheels.< /p>
Features
The Fuel EX Gen 6 has 140/150mm travel with additional adjustment features and more stable handling, plus a more robust frame with storage
You'll enjoy updated components where it matters most, with SRAM's latest GX Eagle AXS wireless electronic drivetrain for smooth shifting under load.
The headset with adjustable angle (angled cups sold separately) and the Mino Link allow you to choose from six different geometry configurations.
The telescopic post allows you to lower the saddle on the fly so it doesn't get in your way in the descents.
We have expanded our range of sizes to adapt to all types of cyclists and we use the wheels that best fit according to the frame size: Size XS uses 27.5" wheels, S allows Choose between 27.5" or 29" wheels, and sizes M and up come with 29" wheels.
Frame Assembly
Frame Alpha Platinum Aluminum, Internal Storage, Set of angle adjustable headset, Mino Link adjustable geometry, adjustable suspension setting, internal cable routing, magnesium rocker link, 34.9mm seat tube, ISCG 05, 55mm chainline, BSA 73, guard down tube, ski lift protector, ABP, UDH, Boost 148, 140 mm travel.
*Fork
Size: S
Fox Rhythm 36, Float EVOL air chamber, GRIP damping, tapered fork tube, 44 mm offset, Boost110, 15 mm Kabolt axle, 140 mm travel
Size: S, M, ML, L, XL, XXL
Fox Rhythm 36, Float EVOL air chamber, GRIP damping, tapered fork tube, 44 mm offset, Boost110, 15 mm Kabolt axle, 150 mm travel
Fox Performance Float X shock, 2-position damping, 185 mm x 55 mm
Maximum compatible fork travel 160mm
Wheels
*Front wheel
Size: S
Bontrager Line Comp 30, Tubeless Ready, 6 bolts, Boost110, 15mm thru axle, 27.5"
Size: S, M, ML, L, XL, XXL
Bontrager Line Comp 30, Tubeless Ready, 6 bolts, Boost110, 15mm thru axle, 29"
*Rear wheel
Size: S
Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12mm thru axle, 27.5"
Size: S, M, ML, L, XL, XXL
Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6 bolts, Boost148, 12mm thru axle, 29"
*Cover
Size: S
Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength casing, aramid rim, 60 tpi, 27.5x2.50"
Size: S, M, ML, L, XL, XXL
Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength casing, aramid rim, 60 tpi, 29x2.50"
Bontrager TLR Sealant Cover Piece, 6oz
Max. size. of the frame Frame: 29x2.50" (XS and S: 27.5x2.50"), Fork: See manufacturer
Electrical system
Battery SRAM eTap battery pack (with charger)
Transmission
SRAM AXS POD shift lever
SRAM GX Eagle AXS rear derailleur, T-Type
SRAM GX Eagle bottom bracket, T-Type, DUB, 30T, 55mm chainline, 170mm length
SRAM DUB MTB Wide bottom bracket, 73 mm, BSA threaded
SRAM Eagle XS-1275 cassette, T-Type, 10-52, 12 speeds
SRAM GX Eagle chain, T-Type, 12 speeds
Maximum chainring size 1x: 34T, oval - 32T, min.: 28T
Components
*Saddle
Size: S, M, ML, L, XL, XXL
Bontrager Verse P3, chromoly rails
Size: S, M, ML, L, XL, XXL
Bontrager Arvada, hollow chromoly rails, width 138 mm
*Seatpost
Size: S
TranzX JD-YSP39, 100 mm travel, internal routing, 34.9 mm
Size: M, ML
TranzX JD-YSP39, 150 mm travel, internal routing, 34.9 mm
Size: L, XL, XXL
TranzX JD-YSP39, 170 mm travel, internal routing, 34.9 mm
*Handlebar
Size: S
Bontrager Line, alloy, 35 mm, height 27.5 mm, width 750 mm
Size: M, ML, L, XL, XXL
Bontrager Line, aluminum, 35 mm, height 27.5 mm, width 780 mm
Bontrager XR Trail Elite grips, nylon lock
*Power
Size: S
Bontrager Elite, 35 mm, 0 degrees, 35 mm length
Size: M, ML, L, XL, XXL
Bontrager Elite, 35 mm, 0 degrees, 45 mm length
*Brake
Size: S, M, ML, L, XL, XXL
SRAM DB 8 4-piston hydraulic disc
Size: S, M, ML, L, XL, XXL
SRAM DB 8 4-piston hydraulic disc
*Brake disc
Size: S, M, ML, L, XL, XXL
SRAM CenterLine, 6 bolts, rounded edge, 180 mm
Size: S, M, ML, L, XL, XXL
SRAM CenterLine, 6 bolts, rounded edge, 200 mm
Disc size Maximum brake disc sizes - Frame: 203mm, Fork: see fork manufacturer
Weight
Weight M - 15.88 kg / 35.01 lbs (with TLR sealant, without tubes)
Weight limit This bicycle has a maximum weight limit (combined weight of bicycle, rider and cargo) of 136 kg.
