It is ideal for you if...
You like technical, twisty descents, but you also want to climb to the top with confidence, lap after lap. You're looking for the cushioning benefits of a carbon frame and wheels, as well as suspension that absorbs impacts and the most demanding terrain.
Features
< p>The Fuel EX Gen 6 has 140/150mm travel with additional fit features and more stable handling, plus a beefier frame with internal storage.
We've expanded our size range to accommodate to all kinds of cyclists and we use the wheels that best fit according to the frame size: Size XS uses 27.5" wheels, S allows you to choose between 27.5" or 29" wheels, and sizes M and above have 29".
It is prepared to destroy thanks to the light carbon wheels that easily grip the terrain and maintain the trajectory when things get complicated.
The storage integrated into the frame allows you to easily carry everything you need, maintaining a stylized and simplified design.
An angle-adjustable headset (angled cups sold separately) and Mino Link let you choose from six different geometry configurations.
Headset Assembly frame
OCLV Mountain Carbon frame, internal storage, headset with angle adjustment, Mino Link adjustable geometry, adjustable suspension setting, internal cable routing, magnesium rocker link, 34.9mm seat tube, ISCG 05, 55mm chainline, BSA 73, downtube guard, lift guard, ABP, UDH, Boost148, 140mm travel
Fox Performance 36 fork, Float EVOL air chamber, GRIP damping, tapered steerer, 44mm offset, Boost110, 15mm Kabolt axle, 150mm travel
Fox Performance Float X shock, 2-position damping, 185 mm x 55 mm
Maximum compatible fork travel 160mm
Wheels
*Front wheel
Size: XS, S
Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, 6 bolts, Boost110, 15mm thru axle, 27.5"
Size: S, M, ML, L, XL
Bontrager Line Elite 30, OCLV Mountain carbon, Tubeless Ready, 6 bolts, Boost110, 15mm thru axle, 29”
*Rear wheel
Size: XS, S
Bontrager Line Elite 30, OCLV Mountain carbon, Tubeless Ready, Rapid Drive 108, 6 bolts, Shimano MicroSpline core, Boost148, 12mm thru axle, 27.5"
Size: XS, S
Bontrager Line Elite 30, OCLV Mountain carbon, Tubeless Ready, Rapid Drive 108, 6 bolts, Shimano MicroSpline core, Boost148, 12 mm thru axle, 27.5”
Size: S, M, ML, L, XL
Bontrager Line Elite 30, OCLV Mountain carbon, Tubeless Ready, Rapid Drive 108, 6 bolts, Shimano MicroSpline core, Boost148, 12mm thru axle, 29”
Rear closure Bontrager Switch thru axle, removable cam
*Cover
Size: XS, S
Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid rim, 60 tpi, 27.5x2.50”
Size: S, M, ML, L, XL
Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid rim, 60 tpi, 29x2.50”
Bontrager TLR Sealant Cover Piece, 6oz
Bontrager TLR rim tape
Max. size. of the frame Frame: 29x2.50" (XS and S: 27.5x2.50"), Fork: See manufacturer
Transmission
Shimano XT M8100 shift lever, 12 speeds
Shimano XT M8100 rear derailleur, long cage
Shimano XT M8120 bottom bracket, 30T, 55mm chain line, 170mm length
Shimano BB-MT501 BSA bottom bracket
Shimano XT M8100 cassette, 10-51, 12 speeds
Shimano Ultegra/XT M8100 chain, 12 speeds
Maximum chainring size 1x: 34T, oval - 32T, min.: 28T
Components
*Saddle
Size: XS, S, M, ML, L, XL
Bontrager Arvada, austenite rails, 138 mm width
Size: XS, S, M, ML, L, XL
Verse Short Comp, steel rails, width 145 mm
*Seatpost
Size: XS, S
Bontrager Line Elite dropper post, 100 mm travel, MaxFlow, internal guidance, 34.9 mm, 345 mm length
Size: M, ML
Bontrager Line Elite dropper post, 150 mm travel, MaxFlow, internal guidance, 34.9 mm, 440 mm length
Size: L
Bontrager Line Elite dropper post, 170 mm travel, MaxFlow, internal guidance, 34.9 mm, 485 mm length
Size: XL
Bontrager Line Elite dropper post, 200 mm travel, MaxFlow, internal guidance, 34.9 mm, 550 mm length
Bontrager Line Pro handlebar, OCLV carbon, 35 mm, height 27.5 mm, width 780 mm
*Handlebar/stem (integrated)
Size: XS, S
Bontrager RSL integrated handlebar and stem system, OCLV carbon, 27.5mm handlebar height, 820mm width, 0 degree stem height, 35mm stem length
Size: M, ML, L, XL
Bontrager RSL integrated handlebar and stem system, OCLV carbon, 27.5mm handlebar height, 820mm width, 0 degree stem height, 45mm stem length
Bontrager XR Trail Elite grips, nylon lock
Bontrager Line Pro stem, 35 mm, Blendr compatible, 0 degrees, 35 mm length
Headset Integrated cartridge bearing, 1-1/8” top, 1.5” bottom, compatible with angle adjustment cup
Shimano XT M8120 4-piston hydraulic disc brake
*Brake disc
Size: XS, S, M, ML, L, XL
Shimano RT86, 6 bolts, 180 mm
Size: M, ML, L, XL
Shimano RT86, 6 bolts, 203 mm
Disc size Maximum brake disc sizes - Frame: 203mm, Fork: see fork manufacturer
Accessories
Bontrager BITS Internal Frame Storage Bag
Weight
Weight M - 14.48 kg / 31.93 lbs (with TLR sealant, without tubes)
Weight limit This bicycle has a maximum weight limit (combined weight of bicycle, rider and cargo) of 136 kg.
