Frame Assembly
Alpha Gold Aluminum frame, tapered head tube , internal derailleur and dropper post routing, ISCG 05, threaded bottom bracket, Boost148, 12mm thru axle
*Fork
- Size: XS - RockShox Recon Silver RL, spring Solo Air, Motion Control shock, lockout, tapered steerer, 37mm offset, Boost110, Maxle Stealth, 140mm travel
- Size: S-XL -RockShox Recon Silver RL, Solo Air spring, Motion Control damper, lockout, tapered steerer, 42mm offset, Boost110, Maxle Stealth, 140mm travel
Maximum compatible fork travel 150mm, XS: 120mm
Wheels
- Shimano MT400 front hub, centerlock, Boost110, 15 mm thru axle
- Shimano MT510 rear hub, centerlock, Boost148, 12 mm thru axle
- Rear closure Bontrager Switch thru-axle, removable cam
*Rim
Size: XS-XL - Bontrager Line Comp 30, Tubeless Ready, 28 holes, Presta valve
Size: S-XL - eThirteen LG1 Enduro rim compatible with tubeless
*Tyre
Size: XS - Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.60 ''
Size: S-XL - Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, rim aramid, 120 tpi, 29x2.60"
Cover Piece Bontrager TLR Sealant, 6oz
Bontrager TLR rim tape
Max. size. Frame: 29x2.60" (XS: 27.5x2.60"), Fork: See manufacturer
Transmission
Shimano Deore M6100 shift lever, 12 speeds
Shimano Deore M6100 rear derailleur, long cage
*Pedalier
Size: XS-L
Shimano MT511, 30D aluminum chainring, 52mm chain line, 170mm length
Size: XL
Shimano MT511, 30D aluminum chainring, 52mm chain line, 175mm length
Shimano SM-BB52 bottom bracket, 73 mm, threaded external bearing
Shimano Deore M6100 cassette, 10-51, 12 speeds
Shimano Deore M6100 chain, 12 speeds
Pedal Nylon platform VP-536
Maximum chainring size 1x: 32T (52mm chain), 36T (55mm chain)
Components
Bontrager Arvada saddle, steel rails, width 138 mm
*Seatpost
Size: XS-S
TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, length 361 mm
Size: M
TranzX JD-YSP18, 130 mm travel, internal routing, 31.6 mm, length 425 mm
Size: M/L-XL
TranzX JD-YSP18, 150 mm travel, internal routing, 31.6 mm, 470 mm length
*Handlebar
Size: XS-S
Bontrager aluminum, 31.8 mm, height 15 mm, width 750 mm
Size: M-XL
Bontrager Rhythm Comp, alloy, 31.8 mm, height 15 mm, width 780 mm
Bontrager XR Trail Comp grips with nylon lock.
*Power
Size: XS-S
Bontrager aluminum, 31.8 mm, Blendr compatible, 7 degrees, length 35 mm
Size: M-XL
Bontrager aluminum, 31.8 mm, Blendr compatible, 7 degrees, 50 mm length
FSA IS-2 headset, 1-1/8" at the top and 1.5" at the bottom
Shimano MT200 hydraulic disc brake
Shimano RT10 brake disc, centerlock, 180 mm
Disc size Maximum brake disc sizes - Frame: 180mm, Fork: see fork manufacturer
Weight
Weight M - 14.30 kg / 31.53 lbs
Weight limit This bike has a maximum weight limit (combined weight of bike, rider and cargo) of 136kg.
